ACDB Box designed for AC-side power distribution and protection in solar PV installations.
Available ACDB + DCDB configurations mentioned in the catalogue:
• 1–3.6 kW — 1Ph — 500V
• 4–7.2 kW — 1Ph — 500V
• 4–7.2 kW — 3Ph — 500V
• 7.3–11.2 kW — 3Ph — 800V
• 7.2–14.4 kW — 3Ph — 1000V
Reference conditions: Voc 45V, Wp 330W. Actual capacity may vary according to solar panel Voc and Wp.
Listed component options include AC MCB, AC SPD, enclosure, cables and electrical accessories.
